Name: PLC Controlled 700-1500 pcs per Hour Simple Structure Paper Egg Tray Machine for Small Business
Brand: Jinan Wanyou Packing Machinery Factory
SKU: ZSJ-700
Price: 130001 USD
Availability: InStock

Zu Hause > produits > Papierei Tray Making Machine >

PLC Controlled 700-1500 pcs per Hour Simple Structure Paper Egg Tray Machine for Small Business

Herkunftsort:

Jinan, Shandong, China

Markenname:

Wanyou

Modellnummer:

ZSJ-700

Kontakt mit uns

Bitte um ein Angebot

PLC Controlled 700-1500 pcs per Hour Simple Structure Paper Egg Tray Machine for Small Business

Einzelheiten zum Produkt

Produktionskapazität:

700-1500 Stück/Stunde

Stromspannung:

220V/380V, 380V, 380V/450V

Leistungsbedarf:

25-100KW

Altpapierverbrauch:

25kg/h-100kg/h

Wasserverbrauch:

75kg/h-300kg/h

Arbeitskraftanforderung:

2-4 Arbeitskräfte

Maschinenlänge:

8m-38m

Maschinengewicht:

8-32 Tonnen

Zahlungs- und Versandbedingungen

Min Bestellmenge

1 Satz

Preis

verhandelbar

Verpackung Informationen

im Behälter

Lieferzeit

20 Werktage nachdem Ablagerungszahlung erhalten

Zahlungsbedingungen

T/T, L/C, Western Union, MoneyGram

Versorgungsmaterial-Fähigkeit

1 Sätze pro Monat

VERWANDTE PRODUKTE

Video

Wein- und Kaffeetassen-Papiertablett / Eiertablett / Kartonherstellungsmaschine / Papierpulpe-Formmaschine

Beste Preis erhalten

Video

Wanyou-PLC-gesteuerte Pulp-Form-Eier-Tray-Maschine 380V/50Hz180KW Power-Papier-Recycling-Eier-Tray-Produktionslinie für kleine Unternehmen

Beste Preis erhalten

Video

PLC-gesteuerte halbautomatische, wechselseitige Formmaschine für Eierfach für kleine Unternehmen

Beste Preis erhalten

Video

Kleine Geschäftsidee Halbautomatische Maschine zur Herstellung von Papier-Eier-Trägern mit PLC-Steuerung

Beste Preis erhalten

Kontakt mit uns

+8615665703348

jnrunliang@hotmail.com

Kontakt jetzt

Beschreibung des Produkts

700-1500 pcs per hour Simple Structure Paper Egg Tray Machine PLC Controlled Semiautomatic Egg Tray Machine for Small Business Paper Product Making Machinery

Quick Detail

Product Type	Egg Tray Machine
Processing Type	Pulp Molding Machine
After-sales Service	Provided Engineers available to service machinery overseas
Application	egg tray,fruit tray,bottle tray
Fuel	Coal, Natural Gas, Disel, LPG and so on
Keyword	egg box/tray machine

Egg tray machine is composed of the following sections:

1. Egg box/Tray Pulping System:

Pulping System
1. Put the raw material and water into the hydraulic pulper, you will get the paper pulp after mixed 10-20 minutes.
2. Pulp pump will transfer the finished paper pulp into the slurry pool.
3. The pulp pond beater will mix the pulp concentration.
4. The pulp pump will transfer the pulp into forming machine.

PLC Controlled 700-1500 pcs per Hour Simple Structure Paper Egg Tray Machine for Small Business 0

2. Egg carton/Tray Molding System :

1. The molding machine is to absorb the pulp to the molding mold, absorb the pulp to the molding mold through the suction of the vacuum system to absorb the excess water into the gas-water separation tank, and then pump the water to the tank for storage.
2. The molding mold absorbs the pulp and then forms it. and then the transfer mold takes out the finished product and sends it to the drying tray inside the dryer oven.

1*2molds paper egg tray machine without dryer 700pcs/h capacity

1*3 molds paper egg tray/carton machine 1000pcs/h capacity

PLC Controlled 700-1500 pcs per Hour Simple Structure Paper Egg Tray Machine for Small Business 2

PLC Controlled 700-1500 pcs per Hour Simple Structure Paper Egg Tray Machine for Small Business 3

1*4 molds paper egg tray machine 1500pcs/h capacity

PLC Controlled 700-1500 pcs per Hour Simple Structure Paper Egg Tray Machine for Small Business 4

Many capacity egg box machine can be choosen:

Egg Tray Mold Quantity

4pcs

Raw material

Waste paper

Egg tray Capacity

1300pcs/hour

Net weight per piece (gram)

70g-75g

Waste paper consumption

530kg/hour

Water Consumption

0.15on/hour

Natural Gas Consumption of Dryer

45cbm/h

Worker requirement

2-3workers

Machine Length

8m-38m

Machine weight

8-32tons

Payment and delivery

Trade terms		FOB Qingdao or EXW Factory
Delivery time		About 30 working days after receiving the deposit.
Payment term		BY T/T 40%DEPOSIT+60%BALANCE or 40% TT Deposit + 70% LC
Time of payment		When the deposit is paid, the machine will begin to be produced. And the balance should be paid by the consignee (the buyer) before the delivery.
Warranty time		Two years after the Egg tray machine received.
TERMS OF DELIVERY		FOB Qingdao Port, China
Package		In container

Installation
1.Usually, all installation and debugging work will be done before shipment. 2. If the buyer wants to Install the debugging term, the seller will arrange one people instructs the installment(all travel ticket and hotel charge by buyer and egineer charge USD100/day )

End productof egg tray machine/egg carton making machine:

PLC Controlled 700-1500 pcs per Hour Simple Structure Paper Egg Tray Machine for Small Business 5

PLC Controlled 700-1500 pcs per Hour Simple Structure Paper Egg Tray Machine for Small Business 6

Welcome to contact us!

Cindy: +86 15665703348
